Used Vertical boring mills, vertical turret lathes, VTLs.

Used, Reconditioned Vertical Boring Mills / Vertical Turret Lathes / VTLs

USED VERTICAL BORING MILLS
USED VERTICAL TURRET LATHES / VTLs

VTL 30", 36", 42" VTL 48", 54", 74" VTLs - 84", 96", 108"

Following are examples of many available subject to prior sale.

30 Inch VTLs

30 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 44 Inches, 36” Turret to Table, 30 HP, 300 Max. Table RPM,
Side Hd., Turret Hd. (Swiveling), Auto Lube, 1952, Good Cond. $19,500.

30 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 44 Inches, 42” Under The Rail, 30 HP, 300 Max. Tabl. RPM,
Turret Head, Side Hd., Three Jaw Chuck, 1958, Good Condition $19,500.

30 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 35 Inches, 22” Under The Rail, 30 HP, 172 Max. Table RPM,
Side Head, Turret Head, 220/440, Pendant Cntl., Good Condition $17,500.

36 Inch VTLs

36 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 41 Inches, 30” Under the Rail, 30 HP, 140 Max. Table RPMs,
Side Head, Turret Head, (1)Ram Head, Low Hours, Nice Condn. $17,500.

36 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 45 Inches, 30” Under The Rail, 30 HP, 180 Max. Tabl. RPM,
Turret Head, 26” Vert. Hd. Trvl., Side Head, 1952, Good Cond. $19,500.

36 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 47 Inches, 30” Under The Rail, 30 HP, 180 Max. Tabl. RPMs,
Swiveling Five-Sided Turret Head, DRO, 1948, In Nice Conditn. $21,500.

42 Inch VTLs

42 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 56 Inches, 33” Under The Rail, 25 HP, 100 Max. Table RPM,
Side Head, 220/440 Volt, Four Jaw,1951 Yr., In Good Condition $27,500.

42 Inch Bullard Manatrol. Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 56 Inches, 36” Under The Rail, 30 HP, 150 Max. Tabl. RPM,
Square Turret Head, Side Head, 3 Jaw, DRO, 1952, Nice Condn. $29,500.

42 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max Swing 56 Inches, 38” Under The Rail, 50 HP, 200 Max. Tabl. RPMs,
Swiveling Turret Head, Side Head, 1952 Year, Rebuilt Recently, $39,500.

42 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 54 Inches, 36” Under The Rail, 30 HP, 150 Max Table RPMs,
Turret Head, Side Hd., Four Jaw Chk., 1952, Excellent Condition $49,500.

46 Inch VTLs

46 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Model 75, Max. Swing 58 Inches, 40” Under Rail, 50 HP, 187 Tabl. RPM,
Turret Head, Side Head, Three Jaw Chuck, In Very Nice Condn. $29,500.

46 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 60 Inches, 40” Under The Rail, 50 HP, 315 Max. Tabl. RPMs,
Turret Head On Rail, Turret Side Head, 3 Jaw, 1967, Nice Cond., $39,500.

46 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Model 75, 59” Max. Swing, 48” Under The Rail, 40 HP, 187 Table RPMs,
Side Head, Square Turret Head, Three Jaw Chuck, In Nice Cond. $44,900.

46 Inch Bullard Dynautrol Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 58 Inches, 40” Under The Rail, 50 HP, 250 Max. Tabl. RPM,
Side Head, Turret Head, Three Jaw Chuck, 1967 Yr., Nice Cond. $49,900.

48 Inch VTLs

48 Inch Webster-Bennett Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 54 Inches, 48” Under The Rail, 75 HP, 100 Max. Tabl. RPM,
Five Station Turret Head, Four Jaw Chuck, DRO, In Nice Cond. $29,500.

48 Inch Giddings & Lewis Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 59 Inches, 48” Under The Rail, 75 HP, 420 Max. Tabl. RPM,
Turret Head, DRO, Chip Conveyor, Six Jaw Chuck, 1967, Good $39,500.

52 Inch VTLs

52 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 59 Inches, 44” Under The Rail, 40 HP, 160 Max. Tabl. RPM,
Swiveling Turret Head, Swiveling Ram Head, Pwr. Elev., Nice, $59,500.

54 Inch VTLs

54 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 62 Inches, 44” Under The Rail, 30 HP, 120 Max. Tabl. RPM,
Turret Head, Side Head, Three Jaw Chuck, 1957 , Good Condn. $49,500.

54 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 62 Inches, 69” Under The Rail, 30 HP, 160 Max. Tabl. RPM,
Swiveling Ram Head, Turret Head, Side Head, Good Condition, $77,500.

54 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 62 Inches, 44” Under The Rail, 30 HP, 120 Max. Tabl. RPM,
Side Head, Swiveling Ram Head, Swiveling Turret Head, Nice, $79,500.

54 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 58 Inches, 68” Under The Rail, 40 HP, 160 Max. Tabl. RPM,
Swiveling Turret Hd., Swiveling Ram Hd., Side Hd.,1953, Nice, $85,000.

57 Inch VTLs

57 Inch Titan CNC Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 65 Inches, 39” Ram Vert. Travel, 50 HP, 250 Max. Tbl. RPM,
Fanuc CNC Control, Four Jaw Chuck, Chip Conv., Nice Condn. $295,000.

62 Inch VTLs

62 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 66 Inches, 53” Under The Rail, 40 HP, 44 Max. Table RPMs,
Turret Head, Side Head, Swiveling Ram Head, 4 Jaw Chck, Nice $44,500.

62 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 72 Inches, 60” Under The Rail, 25 HP, 65 Max. Table RPMs,
Five Position Turret Head, Swiveling Ram Head, In Nice Cond. $44,500.

72 Inch VTLs

72 Inch Cinn. Hypro Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 77 Inches, 65” Under The Rail, 40 HP, 60 Max. Tabl. RPMs,
Two Swiveling Ram Heads, Side Hd., 4 Jaw, 1941, Good Cond. $59,500.

72 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 78 Inches, 61” Under The Rail, 40 HP, 120 Max. Tabl. RPM,
Side Head, Two Ram Heads, DRO, Lube, 1941, Beautiful Cond. $79,500.

74 Inch VTLs

74 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 82 Inches, 62” Under The Rail, 50 HP, 90 Max. Table RPMs,
Two Swiveling Ram Hds., Auto Lube, 1943, In Good Condition $77,500.

74 Inch Bullard Cutmaster Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 82 Inches, 62” Under The Rail, 50 HP, 90 Max. Tabl. RPMs,
Two Swiveling Ram Heads, Auto Lube, 1943 Year, Good Cond. $79,500.

76 Inch VTLs

76 Inch Bullard Dynautrol Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 88 Inches, 72” Under The Rail, 75 HP, 120 Max. Tabl. RPM,
Turret Head, Side Head, Ram Hd., Four Jaw, 1961, Good Cond. $129,500.

76 Inch Bullard Dynautrol Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 88 Inches, 70” Under The Rail, 60 HP, 150 Max Tabl. RPM,
Side Head, Ram Head, 60” Vert. Ram Travl., 1964, Very Good $149,500.

84 Inch VTLs

84 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 90 Inches, 72” Under The Rail, 50 HP, 55 Max. Table RPM,
Two Swiveling Ram Hds., 60 Degrees Right or Left, Good Cnd.$149,500.

86 Inch VTLs

86 Inch Bullard Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 98 Inches, 128” Under Rail, 100 HP, 120 Max. Table RPM,
Two Swiveling Ram Heads, DRO Both Hds., 1967, Low Hrs., $295,500.

96 Inch VTLs

96 Inch King Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 100 Inches, 72” Under The Rail, 50 HP, 60 Max. Tabl. RPM,
Two Swiveling Ram Heads, Side Head, 4 Jaw, Nice Condition $139,500.

97 Inch VTLs

97 Inch Bullard Dynautrol Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 100 Inches, 84” Under the Rail, 75 HP, 120 Max. Tabl. RPM,
Two Turret Hds., DRO, Floor Mountd., 1968 Yr., Good Cond. $139,500.

97 Inch Bullard Dynautrol Vertical Boring Mill/Vertical Turret Lathe
Max. Swing 100 Inches, 84” Under The Rail, 75 HP, 120 Max. Tbl. RPM,
Two Turret Heads, DRO, Floor Mounted, 1967, In Nice Cond. $149,500.

108 Inch VTLs

108 Inch Betts Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 100 Inches, 60” Under The Rail, 75 HP, 10 Max. Table RPM,
Two Ram Heads, Floor Mounted , No Pit, In Very Nice Condn. $129,500.

168 Inch VTLs

168 Inch Niles Vertical Boring Mill/Vertical Turret Lathe/VTL
Max Swing 196 Inches, 178” Under The Rail, 100 HP, 14 Max. Tbl. RPM,
Two Swiveling Ram Heads, 72” Ram Stroke, In Nice Condition $169,500.

300 Inch VTLs

300 Inch Niles CNC Vertical Boring Mill/Vertical Turret Lathe/VTL
Max. Swing 354 Inches, 192” Under the Rail, 150 HP, 20 Max. Tbl. RPM,
Two Ram Heads, Fanuc 4 axis CNC Control, Nice Condition, $4,449,500.

Vertical Boring Mills & VTL’s: In 1905, Giddings & Lewis built their first “boring machine” and today there are numerous brands of vertical boring mills and VTL’s in operation in machining facilities of all types. Though Giddings & Lewis (G&L) is the most popular brand of vertical boring mill, we also sell Bullard, Cincinnati, King, Toshiba and Wotan. We sell both manual and CNC vertical boring mills and VTL’s. Many of the later model G&L vertical boring mills have now been converted to CNC, thus making it difficult to find good late model manual type machines. We therefore invest a lot of time trying to find desirable late model machines. The first thing you’ll need to determine is how large a table/chuck you will need and the weight capacity it will need to have. Then, the second consideration is usually “vertical clearance under the rail;” how tall will your work pieces be? Then, what kind of work heads will you need to do all the different machining operations involved? Depending on which vertical boring mill you buy, it might have a turret head, a side head or one or more ram heads for machining the ID or OD of cylindrical shaped work pieces. Regardless of how large or small a vertical boring mill or VTL you may need, give us a call!

Call 800-834-1952 now or email TomHaleEquipment@gmail.com
